207-2Z SKF 72x35x17mm Calculation factor kr 0.04 Deep groove ball bearings - Industrial Bearing

  207-2Z SKF 72x35x17mm Calculation factor kr 0.04 Deep groove ball bearings

207-2Z SKF 72x35x17mm  Calculation factor kr 0.04 Deep groove ball bearings pdf
Brand SKF
Bearing number 207-2Z
Size (mm) 72x35x17
Bore Diameter (mm) 72
Outer Diameter (mm) 35
Width (mm) 17
d 35 mm
D 72 mm
B 17 mm
d1 46.94 mm
D2 62.69 mm
r1,2 – min. 1.1 mm
da – min. 42 mm
da – max. 46.8 mm
Da – max. 65 mm
ra – max. 1 mm
Basic dynamic load rating – C 27.5 kN
Basic static load rating – C0 22 kN
Fatigue load limit – Pu 0.93 kN
Reference speed 17000 r/min
Limiting speed 8000 r/min
Calculation factor – kr 0.04
Category Single Row Ball Bearings
BDI Inventory 0.0
Manufacturer Name SKF
Minimum Buy Quantity N/A
Weight / Kilogram 0.331
EAN 7316577292735
Product Group – BDI B00308
Enclosure 2 Metal Shields
Precision Class ABEC 1 | ISO P0
Maximum Capacity / Filling Slot Yes
Rolling Element Ball Bearing
Snap Ring No
Internal Special Features No
Cage Material Steel
Internal Clearance C0-Medium
Inch – Metric Metric
Long Description 35MM Bore; 72MM Outside Diameter; 17MM Outer Race Diameter; 2 Metal Shields; Ball Bearing; ABEC 1 | ISO P0; Yes Filling Slot; No Snap Ring; No Internal Special Features
Category – BDI Single Row Ball Bearing
UNSPSC 31171504
Harmonized Tariff Code 8482.10.50.68
Noun Bearing
Keyword String Ball
Manufacturer URL http://www.skf.com
Manufacturer Item Number 207 2Z
Weight / LBS 0.7
Bore 1.378 Inch | 35 Millimeter
Outside Diameter 2.835 Inch | 72 Millimeter
Outer Race Width 0.669 Inch | 17 Millimeter
bore diameter: 35 mm
static load capacity: 22 kN
outside diameter: 72 mm
precision rating: ABEC 3 (ISO Class 6)
overall width: 17 mm
finish/coating: Uncoated
bore type: Round
cage material: Steel
closure type: Double Shielded
outer ring width: 17 mm
row type & fill slot: Single Row Filling Slot
fillet radius: 1 mm
snap ring included: Without Snap Ring
maximum rpm: 10000 RPM
internal clearance: C0
series: 20
dynamic load capacity: 27.5 kN
thrust application warning: This product can not be used in Thrust Applications
d1 46.94 mm
D2 62.69 mm
r1,2 min. 1.1 mm
da min. 42 mm
da max. 46.8 mm
Da max. 65 mm
ra max. 1 mm
Basic dynamic load rating C 27.5 kN
Basic static load rating C0 22 kN
Fatigue load limit Pu 0.93 kN
Calculation factor kr 0.04
Mass bearing 0.31 kg
